JEKKO SPD265C+ User Manual

Page 80 of 97
11 – ENCLOSURE
______________________________________________________________________________________________
. State IN-OUT (Page 2)
DESCRIPTION Higher than 0 > * Equal to 0 > -
7 Ra-p8 slow gears
8 Ra-fungo emergency mushroom push button
OUTPUT ON HEAD O-HO
0 yv solenoid valve 1
1 yv solenoid valve 2
2 yv solenoid valve 3
3 K engine start
4 K automatic switch
5 K speed 1
6 K speed 2
7 yv solenoid valve 4
OUTPUT ON ARM O-AO
0 K buzzer
1 yv switch J2J3
OUTPUT ON SLIM O-SO
0 Front right LED
1 Front left LED
2 Back right LED
3 Back left LED
4 Crane LED
5 Truck LED
6 Index LED on SLIM
7 Green LED on SLIM
8 Yellow LED on SLIM
9 Red LED on SLIM
ANALOGIC
0 Pressure transducer
1 Jib pressure transducer
2 Winch strain gauge
3 Angle sensor
4 right joystick x
5 right joystick y
6 left joystick x
7 left joystick y
8 PWM descent
9 PWM ascent
10 PWM slewing CCW
11 PWM winch descent
12 PWM J1 upward
13 PWM J1 downward
14 PWM J2 upward
15 PWM J2 downward
16 PWM winch descent
17 PWM slewing CW
18 PWM retraction
19 PWM extension
