Parameter setup and measuring operation
LDM52 OEM, Release 003, Revision 000
21
6.4.4 MCT Output/ modification of the operating mode when starting a measure-
ment using the display
When starting a continuous measurement using an external display, you need to define if the
LDM52 OEM should measure based on the operating mode DT or CT.
The operating mode is selected via the command MCT.
When starting a measurement using the display, the predefined operating mode will be applied
as a rule.
When a measurement is started using a communication program or PLC, the command DT or CT
will determine the type of measurement.
Query:
MCT
Set:
MCTx
Range of parameter x:
0 (DT), 1 (CT)
Standard:
0
6.4.5 MF Measuring frequency
MF parameterizes the number x of the measured value outputs per second.
When a value x outside of the measurement range is entered, the lowest or highest permissible
MF value will automatically be set.
Entered value < x MF 0.0
Entered value > x MF 100.0
MF 0 = Automatic measurement. The output frequency ranges between 0.3 Hz and 10 Hz in
most cases. The maximum measuring time will be 6 sec.
Essential factors concerning the measurement period are, among others, the reflectivity
of the target surface and the environmental conditions (e.g. light, fog, rain).
Output: Measurement frequency [MF]: 0.0
The measuring period will be longer when an average value SA ≠ 1 is set!
Query:
MF
Set:
MFx
Range of parameter x:
0.0 …100.0 (Hz), resolution: 0.1
Standard:
0
