6.4.6 MUN – Unit of the measured value
MUNx enables the definition of a unit for the output value. It is shown together with the meas-
ured value.
In order to use MUN, SF 0 must be set.
Query:
MUN
Set:
MUNx
Range of parameter x:
mm, cm, dm, m, in/8, in/16, in, ft, yd
Standard:
mm
Output: Unit for the distances [MUN]: mm
6.4.7 MW – Measurement window
Parameterizes the scope of a measurement window by start x and end y.
Only measured values within the measurement window will be put out.
For example, the measurement window can be used to:
 Eliminate interfering objects before or behind a measurement range
 Define a measurement range
If there is no target object within the defined measurement window, an error message will be
generated cyclically:
 e1207 A target before or behind the measurement window is recognized
 e1203 Target with unsuitable reflectivity
Query:
MW
Set:
MWx y
Range of parameter x:
Resolution: 0.1 mm
Range of parameter y:
Resolution: 0.1 mm
Standard:
-5000000 5000000
Output:
Minimum distance from target [MW]: -5000000 (-500 m)
Maximum distance from target [MW]: 5000000 ( 500 m)
The LDM52 OEM does not check the set measurement window for plausibility. The user is re-
sponsible for correct parameterization!
