Jenoptik LDM51 Series User Manual

Parameter setup and measuring operation
LDM52 OEM, Release 003, Revision 000
27
6.4.13 SD – Data format of the serial interface output
SD parameterizes the output format and the possible output values.
The following outputs are possible:
 Distance
 Signal quality
 Temperature
 Switching outputs (active/ inactive)
Query:
SD
Set:
SDw x y z
Range of parameter w:
0…5
Range of parameter x, y, z:
0 or 1
Standard:
0 0 0 0
Output: [SD]: 0 0 0 0
Separator in correspondence with parameter TE
Parameters for data format SD
Parameter
w
Output format
Separators
between the
values
Unit of
measure
(SF 0 + MUN x)
Example
(SF 0 + MUN mm)
0
decimal
1 separator
unit
d002 925.4 mm = 2925.4 mm
1
decimal
none
none
d002925.4 = 2925.4 mm
2
hexadecimal
(floating point
format IEEE-754)
none
none
h4536E9EC = 2926.6 mm
3
hexadecimal
none
none
h000B6E = 2926 mm
4
binary
none
none
0x80 0x01 0x64 0x46 = 2925.4
mm
5
SSI and switching
outputs only
none
none
SSI: Distance value in 0.1 mm
Switching output: 0 or 1
