Parameter setup and measuring operation
LDM52 OEM, Release 003, Revision 000
6.4.15 SF Scale factor
SFx defines a factor by which the output value is multiplied.
Query:
SF
Set:
SFx
Range of parameter x:
-10.000 …. 10.000
Standard:
0
Output: Scale factor [SF]: 0.000
At SF ≠ 0 the parameter MUN is ineffective.
At SF = 0 the unit defined by MUN becomes effective.
Example of the data output: Scale factor [SF]: 0.000
SF
0
1
2
10
Distance 1,23 m
001230.0 mm
001230.0
002460.0
00012300
6.4.16 SO Set Offset
With the parameter SO a single distance measurement is carried out and set a OF (negative
offset)
SO can only be executed in this way, it is not a parameter in the strict sense. SO is used for the
zero-adjustment of applications, systems, processes.
Input: SO
Output (for example): Offset in 'mm / 10' [SO]: -21091
