Jenoptik LDM51 Series User Manual

Parameter setup and measuring operation
LDM52 OEM, Release 003, Revision 000
37
Areas of application:
 Scanning of static targets.
 Quick measurements on hot surfaces.
 Tracking of continuously quickly moving targets (e.g. crab [crane], vehicle)
Distance jumps or laser beam interruptions can result in faulty measurements!
The warning w1912 is issued.
The tables below show the ranges and accuracies in relation to the target surface for outdoor
applications. The conditions for the measurements were environmental temperature of +25°C
and ambient light around the target of 1.2 kLux.
The measuring range depends on target reflectivity, stray light, output frequency and enviromen-
tal conditions.
Operation Mode CT
Target
Measu-
ring fre-
quency
Measuring range*
Accuracy
Repealibility
(Standard de-
viation)
white, matt, reflectivity approx. 80 %
variabel
15 cm … 100 m
+ 2,5 mm
+ 1,0 mm
20 Hz
15 cm … 40 m
+ 2,1 mm
+ 1,0mm
50 Hz
15 cm … 35 m
+ 2,3 mm
+ 1,2 mm
100 Hz
15 cm … 30 m
+ 3,9 mm
+ 3,9 mm
black, matt, reflectivity approx. 6%
variabel
15 cm … 85 m
+ 2,7 mm
+ 1,3 mm
20 Hz
20 cm … 20 m
+ 2,8 mm
+ 1,8 mm
Reflective tape Oralite special
variabel
15 cm … 100 m
+ 2,1 mm
+ 0,7 mm
20 Hz
20 cm … 100 m
+ 2,1 mm
+ 0,7 mm
50 Hz
20 cm … 100 m
+ 2,1 mm
+ 0,7 mm
100 Hz
20 cm … 100 m
+ 2,1 mm
+ 1,7 mm
Reflective tape Oralite 5200
variabel
50 m … 200 m
+ 2,1 mm
+ 0,7 mm
20 Hz
50 m … 200 m
+ 2,1 mm
+ 0,7 mm
50 Hz
50 m … 200 m
+ 2,1 mm
+ 0,7 mm
100 Hz
50 m … 200 m
+ 2,1 mm
+ 1,7 mm
* in consideration of parameterization in accordance with chapter 6.4.8 and 6.4.16
