Jeti duplex DC-24 II - Page 147

radio control system
EN
6.1.7 Changing the Transmitter Mode from 2 (4) to 1 (3)
The transmitter is equipped with universal gimbals. Both gimbals are
identical, and by adjusting them, the transmitter can be set to modes
1 through 4. After the mechanical adjustment, it is necessary to set
th e sp ec ific m od e of t he t ra nsmit te r in t he
"menu/system/configuration -> Mode 1-4."
2. Deactivating the Throttle Stick and Setting the Center
Position with Spring Centering:
Loosen screws and by turning them counterclockwise
"F”"G”
to the maximum, so that no locking (braking) occurs.
Fig. Fig. 6.38Fig. 6.38
Fig. 6.39Fig. 6.39Fig. 6.39
(a)
(b)
Fig.Fig. 6.37Fig. 6.37
(c)
Loosen screw by turning it counterclockwise to the maximum, "C”
which will gradually activate the center return spring. You can adjust
the strength of the return spring using the adjustment screw .
"D”
G
-
F
-
Fig. 6.40Fig. 6.40Fig. 6.40
Fig. 6.41Fig. 6.41Fig. 6.41
C
-
+
D
Fig. 6.42Fig. 6.42Fig. 6.42Fig. 6.43Fig. 6.43Fig. 6.43
LeftLeft
LeftLeft
(a)
1.
Place the
magnetic key
(a)
on the cover ring
(b) of the gimbal
and remove it
from position .
(c)
63
