SECTION 3 - MACHINE OPERATION
31215821 3-13
Brake Release Button
The machine must be POWERED ON and the Ground Control
Station set to the GROUND CONTROL MODE to manually release
the brakes. The brakes only DISENGAGE (electrically) when the
joystick control is moved off center during driving or are manu-
ally DISENGAGED (electrically) using the Brake Release Button
on the front of the Ground Control Station.
NOTE: If the machine’s batteries are completely depleted of elec-
trical charge, the brakes cannot be released manually.
DO NOT MANUALLY DISENGAGE THE BRAKES UNLESS MACHINE IS SITTING
ON A LEVEL SURFACE OR MACHINE IS FULLY RESTRAINED.
Platform Up and Down Buttons
PUSH and RELEASE -
TO DISENGAGE Brakes
PUSH and RELEASE AGAIN -
TO ENGAGE Brakes
PUSH IN -
TO ELEVATE Platform
RELEASE -
TO STOP ELEVATING
PUSH IN -
TO LOWER Platform
RELEASE -
TO STOP LOWERING
