SECTION 3 - MACHINE OPERATION
3-34 31215821
Power Tray Height Adjustment
The power tray is designed to carry up to 198 lb (90 kg) of
weight. It can be quickly and easily raised or lowered vertically
on the front of the mast assembly using the switch located in
the platform.
1. Push the power tray switch UP to raise the tray to
the desired height.
2. When desired tray height is achieved, release the
power tray switch.
3. Push the power tray switch DOWN to lower the
tray.
R
R
Figure 3-14. Power Tray Height Adjustment
1. Power Tray Switch
1
