Table 13: System 450 Web UI Overview Page Descriptions, User Actions, and References (Part 1 of 2)
Callout
Number
Identifier
Item Name
User Actions, Descriptions, References
1Name
Login Field
Enter the assigned System 450 web user name here.
Note: You can assign a web user name in the Web User Name: field in the Web Server
section on the Network Configuration page. See Network Configuration Page
on
page 41 for more information about assigning a user name.
In this example, WebUserName is entered as the assigned login name. The default web
user name is System450User1.
2 Password
Login Field
Enter the assigned System 450 web password here.
Note: You can assign a web password in the Web Password: field in the Web Server
section on the Network Configuration page. See Network Configuration Page
on
page 41.
In this example, a password is entered. The default web password is Wx9jc3.
3Login
Button
After entering the assigned web user name and web password, click Login to log in to the
System 450 web UI. The System Configuration page appears. See System Configuration
Page on page 31 for more information.
4Sn-1:
Sensor 1 Name
Identifies the Sn-1 (Sensor 1) and displays the assigned Sn-1 name.
Note: You have the option to assign a sensor name for Sn-1 in the Name field in the Sn-1:
Sensor 1 section on the Sensor Configuration Page
.
In this example, the assigned sensor name for Sn-1 is Cond Press Cntrl.
5 Sn-1 Status Displays the current condition status sensed at Sn-1.
6Sn-2:
Sensor 2 Name
Identifies the Sn-2 (Sensor 2) and displays the assigned Sn-2 name.
Note: You have the option to assign a sensor name for Sn-2 in the Name field in the Sn-2:
Sensor 2 section on the Sensor Configuration Page
.
In this example, the assigned sensor name for Sn-2 is Room Temp Cntrl.
7 Sn-2 Status Displays the current condition status sensed at Sn-2.
8 Sn-3
Sensor 3 Name
Identifies the Sn-3 (Sensor 3) and displays the assigned Sn-3 name.
Note: You have the option to assign a sensor name for Sn-3 in the Name field in the Sn-3:
Sensor 3 section on the Sensor Configuration Page
In this example, the assigned sensor name for Sn-3 is %rH Cntrl.
9Sn-3: Status Displays the current condition status sensed at Sn-3.
10 Communications
Status
Displays the current status of communication between your System 450 communications
control module and the connected LAN, WAN, or Internet. Communications status is
defined as OK or FAIL.
11 Site
Name Field
Displays the assigned site name.
Note: You have the option to assign a site name for your System 450 control system in
the Site Name: field in the Web Server section on the Network Configuration page.
See Network Configuration Page
on page 41 for more information.
