System 450™ Series Control Module with Ethernet Communications Installation Instructions30
12 Analog Outputs
Status Section
Displays the setup values for each analog output in your control system, including the
configured control ramp icon, analog output name (NAME), output signal status (STATUS),
referenced sensor (SENS), setpoint (SP), end point (EP), output signal strength at setpoint
(OSP), output signal strength at end point (OEP), integration constant (I-C), output signal
update rate (UP-R), output signal dead band (bNd), and sensor failure mode (SNF).
See Analog Output Configuration Page
on page 36 for more information on setting up
analog outputs in the System 450 web UI.
13 STATUS
of Analog Output
Signal
Displays the current status of each analog output in your control system as a percentage of
the total output signal strength range.
In this example, OUTA-1 (Analog Output 1) is providing an output signal that is 90% of the
full signal strength, and OUTA-2 (Analog Output 2) is providing an output signal that is 45%
of the full signal strength.
14 Relay Outputs
Status Section
Displays the setup values for each relay output in your control system, including relay
name (NAME), relay output status (STATUS), referenced sensor (SENS), relay on value
(ON), relay off value (OFF), on-delay value (ONd), off-delay value (OFFd), minimum on
time (ONT), minimum off time (OFFT) and sensor failure mode (SNF).
See Relay Output Configuration Page on page 39 for more information on setting up relay
outputs in the System 450 web UI.
15 STATUS
of Relay Output
Displays the current status of each relay output in your control system as either On or Off.
In this example, OUTR-3 (Relay Output 3) is off, and OUTR-4 (Relay Output 4) is on.
16 About
Button
Click About to display the System 450 Control Firmware ssm number and version, the
Control CPU type, the Terminal Firmware ssm number and version, and the Terminal CPU
type. This information is used to troubleshoot advanced control and firmware problems.
See About Page
on page 45 for more information.
Table 13: System 450 Web UI Overview Page Descriptions, User Actions, and References (Part 2 of 2)
Callout
Number
Identifier
Item Name
User Actions, Descriptions, References
