4. Name of Parts and Indications for Safety Consideration
Safety labels are afxed to the indoor unit in order to ensure safe use.
Read and understand this manual before using the indoor unit.
Indoor Unit
Air Outlet
Louver
Flat Panel
(The air lter is
attached inside.)
Wired Controller or
Wireless Controller
(Option)
Location of Indoor Unit Model
Indication
● It is indicated on the unit nameplate
attached at bottom left.
4.1 Wall Mount Type
Air Inlet
Electrical Hazard
Located on electrical
box cover.
Front Cover Panel
WARNING Label
Safety Label
●
Attached to the part indicated by .
WARNING Label
Receiver and Indicator
Indicator
Receiver
Indicator
Receiver
TIWM006B22S, TIWM008B22S
and TIWM012B22S
TIWM015B22S, TIWM018B22S
TIWM024B22S and TIWM030B22S
: TIMER
: FILTER/DEFROST
: RUN
