P5417089
21
5.2.2 Temperature, Fan Speed and Air Flow Direction Setting
Tempera-
ture
Point the transmitter towards the receiver and press
“Temp” switch to set the temperature.
By pressing “ ”, the temperature is increased by
1°F (0.5°C).
By pressing “ ”, the temperature is decreased by
1°F (0.5°C).
The set temperature is set
to 83°F (28
o
C) in the cooling
operation.
● The available set temperature range is 66°F (19°C) to 86°F (30°C) during cooling, dry or fan operation.
When the wireless controller is pressed, the transmitting indicator “
“ ashes on the LCD display of
the wireless controller and the beeping sound is heard from the indoor unit.
NOTE
Fan
Speed
Point the transmitter towards the receiver and press
“Fan ” switch to set the fan speed.
By repeatedly pressing the switch, the setting
changes sequentially as shown below.
“MED” is normally used.
The fan speed is set to “HIGH”
in the cooling operation.
● The fan speed can be set for each operating mode except Dry mode, which forces fan operation at
“
LOW
”
speed only.
Air Flow
Direction
Point the transmitter towards the receiver and press “Louver ” switch to set the louver
angle.
By pressing “Louver ” switch, the louver angle is changed as follows.
NOTE:
Auto-swing and 1 step to 5 step louver settings are only available for the cooling and dry
modes.
● Louver settings are automatically changed during heating, cooling, or dry operation.
1 Step
Auto
Swing2 Step 3 Step 4 Step 5 Step 6 Step 7 Step
LOW → MED → HIGH → HIGH2 → AUTO
To Next Page
