Chapter 4
2. Press [9][9][8]
OR
Scroll to Bypass Options using the keys [<][>] and press [*]. Scroll to
Bypass Open Zones and press [*].
Press (*) for <>
Bypass Options
Press (*) for <>
Bypass Op. Zones
3. To exit bypassing mode, press [*].
4. If the system is ready to arm the Ready indicator will be lit. When
arming the system, a bypass warning briefly displays.
To Recall the Last Bypassed Zones LCD Display
1. Press [*][1]. If required enter your access code or present your prox-
imity tag.
Zone Bypass <>
(*) To Bypass
2. Press [9][9][9]
OR
Scroll to Bypass Options and press [*]. Scroll to Bypass Recall
using [<][>] the keys and press [*].
Press (*) for <>
Bypass Recall
then
3. To exit bypassing mode press [*].
4. If the system is ready to arm the Ready indicator will be lit. When
arming the system, a bypass warning briefly displays.
To Clear the Bypass Indication from All Zones LCD Display
1. Press [*][1]. If required enter your access code or present your prox-
imity tag.
Zone Bypass <>
(*) To Bypass
2. Press [0][0][0]
OR
Scroll to clear bypasses using the [<][>] keys and press [*]. All
bypassed zones will now be open.
Press (*) for <>
Clear Bypasses
then
Bypass Cleared
Zones Unbypassed
3. To exit bypassing mode press [*].
4.10 Bypass Groups
Program frequently bypassed zones into the system as a bypass group. Using bypass groups avoids indi-
vidually bypassing each zone. One bypass group can be programmed per partition.
NOTE: This feature is not to be used in UL listed installations.
To Program a Bypass Group LCD Display
1. Press [*][1]. If required enter your access code or present your prox-
imity tag.
Scroll to <>
Bypass Zones
2. Enter the 3 digit zone # of all zones you want bypassed
OR
Scroll to and press [*] to indicate all zones you want bypassed.
