Trouble
Condition
Trouble
Level 1
Description Trouble Types
Trouble
Level 2
Notification
Level 3
Communications 11 The system has detected a com-
munication trouble. Call for service.
TLM 01 n/a
FTC 02 Receiver
1-4
SIM Lock 03 n/a
Cellular 04 n/a
Ethernet 05 n/a
Receiver 06 Receiver
1-4
Supervision
Receiver
07 Receiver
1-4
Alt Comm Fault 09 n/a
Alt Comm FTC 10 Receiver
1-4
Not Networked 12 The system has detected a network
trouble condition with one or more
modules on the system.
If the trouble does not restore within
20 minutes, call for service.
Zone 01 Zone label
001-128
Keypad 02 Keypad 1-
16
Siren 03 Siren 1-16
Repeater 04 Repeater
1-8
User 05 Users
01-1000
AUX Trouble 13 The system has detected a trouble
on the AUX terminal.
Zone 01 Zone
Power
Supply
05 Power Sup-
ply 1-8
High-current
O/P
06 Module 1-4
System Area 07 n/a
8 I/O Module 10 Module 1-
15
Bus Repeater 11 Repeater
1-8
3A Power Sup-
ply Aux 1
12 Aux 1
Trouble
3A Power Sup-
ply Aux 2
13 Aux 2
Trouble
- 38 -
Chapter 11
