FORM 160.10-O1
ISSUE DATE: 4/27/2018
APPENDIX B - PROGRAMMABLE SETPOINT VALUES
COMPRESSOR SCREEN
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Vent Line Off State Service De-Energized Energized De-Energized
HOT GAS BYPASS SCREEN (COMPRESSOR SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Close Percentage Service 5 % 15 % 5 %
Hold Period Service 30 Min 120 Min 30 Min
Surge Sensitivity Service 0.1 1.3 0.3
Minimum Load Service 0 °F 4 °F 0°F
VSD CALIBRATION SCREEN (COMPRESSOR SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Increment Amount Service 0.1 Hz 10.0 Hz 1 Hz
SURGE PROTECTION SCREEN (COMPRESSOR SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Shutdown Service Disabled Enabled Enabled
Extended Run Service Disabled Enabled Disabled
Count Window Service 1 Min 5 Min 3 Min
Count Limit Service 4 20 15
Surge Sensitivity Service 0.3 1.3 0.3
OIL SUMP SCREEN
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Manual Pump Operator Disabled Enabled Disabled
Low Pressure Limit Service 10 PSID 40 PSID 25 PSID
Prelube Time Service 15 Seconds 60 Seconds 30 Seconds
Coastdown Time Service 150 Seconds 600 Seconds 150 Seconds
Heater Setpoint Service 125 °F 155 °F 140 °F
ELECTROMECHANICAL STARTER SCREEN
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Local Motor Current Limit Operator 30 % 100 % 100 %
Pulldown Demand Limit Operator 30 % 100 % 100 %
Pulldown Demand Time Operator 0 Min 255 Min 0 Min
TABLE 13 - PROGRAMMABLE SETPOINT VALUES (CONT’D)
