APPENDIX B - PROGRAMMABLE SETPOINT VALUES
FORM 160.10-O1
ISSUE DATE: 4/27/2018
B
(MOD “B”) SOLID STATE STARTER SCREEN
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Local Motor Current Limit Operator 30 % 100 % 100 %
Pulldown Demand Limit Operator 30 % 100 % 100 %
Pulldown Demand Time Operator 0 Min 255 Min 0 Min
Full Load Amps Service 35 Amps 1050 Amps 35 Amps
Voltage Range Service
Disabled, 200-208, 220-240, 380,
400, 415, 440-480, 550 – 600
Disabled
Starting Current Service 310 Amps 3300 Amps 310 Amps
Open SCR Service Disabled Enabled Disabled
Shorted SCR Service Disabled Enabled Enabled
VARIABLE SPEED DRIVE SCREEN
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Local Motor Current Limit Operator 30 % 100 % 100 %
Pulldown Demand Limit Operator 30 % 100 % 100 %
Pulldown Demand Time Operator 0 Min 255 Min 0 Min
Filter Inhibit Service Disabled Enabled Disabled
VARIABLE SPEED DRIVE DETAILS SCREEN (VARIABLE SPEED DRIVE SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Local Motor Current Limit Operator 30 % 100 % 100 %
Pulldown Demand Limit Operator 30 % 100 % 100 %
Pulldown Demand Time Operator 0 Min 255 Min 0 Min
ADAPTIVE CAPACITY CONTROL DETAILS SCREEN (VARIABLE SPEED DRIVE SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Local Motor Current Limit Service 30 % 100 % 100 %
Pulldown Demand Limit Service 30 % 100 % 100 %
Pulldown Demand Time Service 0 Min 255 Min 0 Min
Stability Limit Service 1000 7000 4500
Surge Margin Adjust Service 0.0 Hz 25.0 Hz 0.0 Hz
ACC Auto Map Print Service Disabled Enabled Disabled
HARMONIC FILTER (VARIABLE SPEED DRIVE SUBSCREEN)
SETPOINT
ACCESS
LEVEL
MINIMUM
VALUE
MAXIMUM
VALUE
DEFAULT
Local Motor Current Limit Operator 30 % 100 % 100 %
Pulldown Demand Limit Operator 30 % 100 % 100 %
Pulldown Demand Time Operator 0 Min 255 Min 0 Min
TABLE 13 - PROGRAMMABLE SETPOINT VALUES (CONT’D)
