Table 9: Q6 compressor, evaporator - condenser shell codes
Series E–E F–F
A 7 ft 0 in. 7 ft 0 in.
B 8 ft 3 in. 8 ft 3 in.
C 1 ft 7 1/2 in. 1 ft 7 1/2 in.
D 1 ft 5 1/2 in. 1 ft 5 1/2 in.
E 12 ft 0 in. 16 ft - 0 in.
Table 10: P7, Q7 compressor, evaporator - condenser shell codes
Series E–E E–I F–F
A 6 ft 2 in. 7 ft 1 3/4 in. 6 ft 2 in.
B 8 ft 0 5/8 in. 8 ft 8 in. 7 ft 6 1/2 in.
C 1 ft 7 1/2 in. 1 ft 7 1/2 in. 1 ft 7 1/2 in.
D 1 ft 5 1/2 in. 1 ft 11 3/8 in. 1 ft 5 1/2 in.
E 12 ft 0 in. 12 ft 0 in. 16 ft 0 in.
Table 11: P8 compressor, evaporator - condenser shell codes
Series G–E H–F J–J L–L
A 6 ft 11 in. 6 ft 11 in. 7 ft 6 1/2 in. 7 ft 6 1/2 in.
B 10 ft 6 in. 10 ft 6 in. 10 ft 11 in. 10 ft 11 in.
C 2 ft 0 in. 2 ft 0 in. 2 ft 1 1/4 in. 2 ft 1 1/4 in.
D 1 ft 5 1/2 in. 1 ft 5 1/2 in. 1 ft 8 in. 1 ft 8 in.
E 12 ft 0 in. 16 ft 0 in. 12 ft 0 in. 16 ft 0 in.
Table 12: P9 compressor, evaporator - condenser shell codes
Series H–F J–J L–L
A 6 ft 11 in. 7 ft 6 1/2 in. 7 ft 6 1/2 in.
B 10 ft 3 in. 10 ft 8 1/2 in. 10 ft 8 1/2 in.
C 2 ft 0 in. 2 ft 1 1/4 in. 2 ft 1 1/4 in.
D 1 ft 5 1/2 in. 1 ft 8 in. 1 ft 8 in.
E 16 ft 0 in. 12 ft 0 in. 16 ft 0 in.
Note:
1. All dimensions are approximate.
2. For compact waterboxes, see Figure 13, determine overall unit length by adding
waterbox depth to tube sheet length.
3. Water nozzles can be located on either end of unit. Add 1/2 in. (13 mm) to nozzle length
for flanges connections.
4. To determine overall height, add 7/8 in. (22 mm) for isolators.
5. Use of motors with motor hoods may increase overall unit dimensions.
33Model YK (Style G) Centrifugal Liquid Chiller
