Johnson Controls YORK YK Series - Condenser Marine Waterbox Nozzle Arrangements - ft in. (mm)

Condenser marine waterbox nozzle arrangements - ft in.
(mm)
Figure 33: Dimensions of condenser marine waterboxes ft in. (mm)
Table 54: Dimensions of marine waterboxes - 150 psi round
Nozzle pipe
size in. (mm)
Number of passes
1-pass 2-pass 3-passCondenser
shell code
1 2 3 D
S
5
S
5
T
5
U
S
5
T
5
U
A 10 in.
(254)
6 in.
(152)
6 in.
(152)
1 ft 3 in.
(381)
3 ft 11 in.
(1,194)
3 ft 11 in.
(1,194)
1 ft 8 in.
(508)
1 ft 3
3/8 in.
(391)
3 ft 11 in.
(1,194)
1 ft 8 in.
(508)
1 ft 3
3/8 in.
(391)
C,D 12 in.
(305)
8 in.
(203)
6 in.
(152)
1 ft 3
1/2 in.
(394)
4 ft 3 in.
(1,295)
4 ft 3 in.
(1,295)
1 ft 8 in.
(508)
1 ft 6
1/2 in.
(470)
4 ft 3 in.
(1,295)
1 ft 8 in.
(508)
1 ft 6
1/2 in.
(470)
E,F 14 in.
(356)
10 in.
(254)
8 in.
(203)
1 ft 5
1/2 in.
(445)
4 ft 7 in.
(1,397)
4 ft 7 in.
(1,397)
1 ft 10
in.
(559)
1 ft 9 in.
(533)
4 ft 7 in.
(1,397)
1 ft 10
in.
(559)
1 ft 9 in.
(533)
J,K,L 16 in.
(406)
10 in.
(254)
10 in.
(254)
1 ft 8 in.
(508)
5 ft 1 in.
(1,549)
5 ft 1 in.
(1,549)
1 ft 9 in.
(533)
1 ft 9
1/2 in.
(546)
5 ft 1 in.
(1,549)
1 ft 9 in.
(533)
1 ft 9
1/2 in.
(546)
M,N 20 in.
(508)
14 in.
(356)
10 in.
(254)
1 ft 11
in.
(584)
5 ft 9 7/8
in.
(1,775)
5 ft 9 7/8
in.
(1,775)
2 ft 4 in.
(711)
2 ft 1
1/2 in.
(648)
5 ft 9 7/8
in.
(1,775)
2 ft 4 in.
(711)
2 ft 1
1/2 in.
(648)
Model YK (Style G) Centrifugal Liquid Chiller58
