See note in P and Q compressor units (standard).
Evaporator - compact waterboxes - A through L evaporators -
ft in. (mm)
Figure 25: Dimensions of evaporator compact waterboxes A through L evaporators ft in. (mm)
Table 46: Dimensions of compact waterboxes - 150 psi round
Nozzle pipe size in. (mm) Evaporator nozzle dimensions ft in. (mm)
Number of passes 1-pass 2-pass 3-pass
Condenser shell code
1 2 3 C
AA
5
BB
5
DD
5
BB
5
DD
5
A 8 in.
(203)
6 in.
(152)
4 in.
(101)
1 ft 3 1/2
in.
(394)
1 ft 10 in.
(559)
1 ft 2 in.
(356)
2 ft 6 in.
(762)
1 ft 2 in.
(356)
2 ft 6 in.
(762)
C,D 10 in.
(254)
8 in.
(203)
6 in.
(152)
1 ft 5 1/2
in.
(445)
2 ft 0 in.
(610)
1 ft 3 in.
(381)
2 ft 9 in.
(838)
1 ft 3 in.
(381)
2 ft 9 in.
(838)
E,F 14 in.
(355)
10 in.
(254)
8 in.
(203)
1 ft 7 in.
(483)
2 ft 2 in.
(660)
1 ft 4 in.
(406)
3 ft 0 in.
(914)
1 ft 4 in.
(406)
3 ft 0 in.
(914)
G,H 14 in.
(355)
10 in.
(254)
8 in.
(203)
2 ft 0 in.
(610)
2 ft 3 1/2
in.
(699)
1 ft 3 1/2
in.
(394)
3 ft 3 1/2
in.
(1,003)
1 ft 3 1/2
in.
(394)
3 ft 3 1/2
in.
(1,003)
I,J,K,L 16 in.
(406)
12 in.
(305)
10 in.
(254)
2 ft 1 1/4
in.
(641)
2 ft 6 in.
(762)
1 ft 5 in.
(432)
3 ft 7 in.
(1,092)
1 ft 5 in.
(432)
3 ft 7 in.
(432)
45Model YK (Style G) Centrifugal Liquid Chiller
