Johnson Controls YORK YK Series User Manual

Figure 23: Two pass condensers dimensions
Table 42: Two pass condensers, shell codes ft in. (mm)
Dimensions A C,D E,F J,K,L M,N P,Q R,S T,V,W X,Z
H 1 ft 1 7/8
in.
(352)
1 ft 1 7/8
in.
(352)
1 ft 3 in.
(381)
1 ft 4 in.
(406)
1 ft 2 7/8
in.
(378)
1 ft 4 7/8
in.
(429)
1 ft 7 3/8
in.
(492)
1 ft 7 1/2
in.
(495)
1 ft 9 3/4
in.
(552)
J 0 ft 5 7/8
in.
(149)
0 ft 6 1/2
in.
(165)
0 ft 7 in.
(178)
0 ft 7 1/2
in.
(191)
0 ft 7 3/4
in.
(197)
0 ft 9 1/2
in.
(241)
0 ft 11 3/4
in.
(298)
0 ft 11 in.
(279)
1 ft 1 7/8
in.
(352)
Table 43: Double bundle heat recovery condensers, shell codes
B I O U Y
Dimensions Tower Heating Tower Heating Tower Heating Tower Heating Tower Heating
H 1 ft 6 1/2
in.
(470)
1 ft 5 in.
(432)
1 ft 7 1/2
in.
(495)
1 ft 4 3/4
in.
(425)
1 ft 9 1/2
in.
(546)
1 ft 6 in.
(457)
1 ft 10 1/4
in.
(565)
1 ft 8 in.
(508)
2 ft 4 3/4
in.
(730)
1 ft 10 1/2
in.
(572)
J 0 ft 10 1/2
in.
(267)
0 ft 9 in.
(229)
0 ft 11 1/2
in.
(292)
0 ft 8 3/4
in.
(222)
1 ft 1 1/2
in.
(343)
0 ft 10 in.
(254)
1 ft 2 1/4
in.
(362)
1 ft 0 in.
(305)
1 ft 8 3/4
in.
(527)
1 ft 2 1/2
in.
(368)
Figure 24: Three pass condensers dimensions
Table 44: Three pass condensers, shell codes ft in. (mm)
Dimensions A C,D E,F J,K,L M,N P,Q R,S T,V,W X,Z
H 1 ft 1 7/8
in.
(352)
1 ft 1 7/8
in.
(352)
1 ft 3 in.
(381)
1 ft 3 1/2
in.
(394)
1 ft 3 3/8
in.
(391)
1 ft 5 1/2
in.
(445)
1 ft 7 3/8
in.
(492)
1 ft 7 1/2
in.
(495)
1 ft 7 3/8
in.
(492)
Table 45: Double bundle heat recovery condensers, shell codes
B I O U Y
Dimensions Tower Heating Tower Heating Tower Heating Tower Heating Tower Heating
H 1 ft 6 1/2
in.
(470)
1 ft 5 in.
(432)
1 ft 7 1/2
in.
(495)
1 ft 4 3/4
in.
(425)
1 ft 9 1/2
in.
(546)
1 ft 6 in.
(457)
1 ft 10 1/4
in.
(565)
1 ft 8 in.
(508)
2 ft 4 3/4
in.
(730)
1 ft 10 1/2
in.
(572)
Model YK (Style G) Centrifugal Liquid Chiller44
