Johnson Controls YORK YK Series User Manual

Table 48: Dimensions of compact waterboxes - 150 psi round
Nozzle pipe size in. (mm) Condenser nozzle dimensions ft in. (mm)
Number of passes 1-pass 2-pass 3-pass
Condenser shell code
1 2 3 D
CC
5
BB
5
DD
5
BB
5
DD
5
J,K,L 16 in.
(406)
10 in.
(254)
10 in.
(254)
1 ft 8 in.
(508)
3 ft 0 in.
(914)
2 ft 3 in.
(686)
3 ft 9 in.
(1,143)
2 ft 3 in.
(686)
3 ft 9 in.
(1,143)
M,N 20 in.
(508)
14 in.
(356)
10 in.
(254)
1 ft 11 in.
(584)
3 ft 6 in.
(1,067)
2 ft 6 3/8
in.
(772)
4 ft 5 5/8 in.
(1,362)
2 ft 6 3/8
in.
(772)
4 ft 5 5/8 in.
(1,362)
P,Q 20 in.
(508)
16 in.
(406)
14 in.
(356)
2 ft 1 1/4
in.
(641)
3 ft 8 in.
(1,118)
2 ft 7 in.
(787)
4 ft 9 in.
(1,448)
2 ft 7 in.
(787)
4 ft 9 in.
(1,448)
See note in Evaporator - compact waterboxes - A through L evaporators - ft in. (mm).
Condenser - compact waterboxes - R through Z - standard -
ft in. (mm)
Figure 28: Dimensions of condenser compact waterboxes - R through Z - standard (mm)
Model YK (Style G) Centrifugal Liquid Chiller50
