Johnson Controls YORK YK Series User Manual

Table 49: Dimensions of compact waterboxes - 150 psi round
Nozzle pipe size in. (mm) Condenser nozzle dimensions ft in. (mm)
Number of passes 1-pass 2-pass 3-pass
Condenser shell code
1 2 3 D
CC
5
BB
5
DD
5
BB
5
DD
5
R,S 20 in.
(508)
18 in.
(457)
14 in.
(356)
2 ft 3 1/2
in.
(699)
3 ft 10 1/2
in.
(1,181)
2 ft 9 1/2
in.
(851)
4 ft 11 1/2
in.
(1,511)
2 ft 9 1/2
in.
(851)
4 ft 11 1/2
in.
(1,511)
T,V,W 24 in.
(610)
18 in.
(457)
16 in.
(406)
2 ft 5 1/2
in.
(749)
3 ft 11 1/2
in.
(1,207)
2 ft 9 in.
(838)
5 ft 2 in.
(1,575)
2 ft 9 in.
(838)
5 ft 2 in.
(1,575)
X,Z 24 in.
(610)
20 in.
(508)
16 in.
(406)
2 ft 8 in.
(813)
4 ft 1 1/4
in.
(1,251)
2 ft 9 1/4
in.
(845)
5 ft 5 1/4 in.
(1,657)
2 ft 9 1/4
in.
(845)
5 ft 5 1/4 in.
(1,657)
See note in Evaporator - compact waterboxes - A through L evaporators - ft in. (mm).
Condenser - heat recovery compact waterboxes - standard -
ft in. (mm)
Figure 29: Dimensions of condenser heat recovery compact waterboxes - standard (mm)
51Model YK (Style G) Centrifugal Liquid Chiller
