Evaporator compact waterboxes - ft in. (mm)
Figure 19: One pass evaporator dimensions
Table 37: Two pass evaporators, shell codes ft in. (mm)
Dimensions A C,D E,F G,H I,J,K,L M,N P,Q R,S,W X,Z
F 1 ft 2 1/4
in.
(362)
1 ft 3 in.
(381)
1 ft 3 1/2
in.
(394)
1 ft 3 3/4
in.
(400)
1 ft 5 1/2
in.
(445)
1 ft 11 5/8
in.
(600)
1 ft 11 5/8
in.
(600)
2 ft 0 5/8
in.
(625)
2 ft 1 3/4
in.
(654)
Figure 20: Two pass evaporator dimensions
Table 38: One pass evaporators, shell codes in. (mm)
Dimensions A C,D E,F G,H I,J,K,L M,N P,Q P,S,W X,Z
F 1 ft 2 1/4
in.
(362)
1 ft 3 in.
(381)
1 ft 3 1/2
in.
(394)
1 ft 3 3/4
in.
(400)
1 ft 5 1/2
in.
(445)
1 ft 11 5/8
in.
(600)
1 ft 11 5/8
in.
(600)
2 ft 0 5/8
in.
(625)
2 ft 1 3/4
in.
(654)
G 0 ft 6 1/2
in.
(165)
0 ft 7 in.
(178)
0 ft 7 1/2
in.
(191)
0 ft 7 3/4
in.
(197)
0 ft 9 1/2
in.
(241)
1 ft 3 5/8
in.
(397)
1 ft 3 5/8
in.
(397)
1 ft 3 5/8
in.
(425)
1 ft 5 3/4
in.
(451)
Model YK (Style G) Centrifugal Liquid Chiller42
