Johnson Controls YORK YK Series User Manual

Condenser - compact waterboxes - A through Q - standard -
ft in. (mm)
Figure 27: Dimensions of condenser compact waterboxes - A through Q - standard (mm)
Table 48: Dimensions of compact waterboxes - 150 psi round
Nozzle pipe size in. (mm) Condenser nozzle dimensions ft in. (mm)
Number of passes 1-pass 2-pass 3-pass
Condenser shell code
1 2 3 D
CC
5
BB
5
DD
5
BB
5
DD
5
A 10 in.
(254)
6 in.
(152)
6 in.
(152)
1 ft 3 in.
(381)
2 ft 4 in.
(711)
1 ft 9 1/2
in.
(546)
2 ft 10 1/2
in.
(876)
1 ft 9 1/2
in.
(546)
2 ft 10 1/2
in.
(876)
C,D 12 in.
(305)
8 in.
(203)
6 in.
(152)
1 ft 3 1/2
in.
(394)
2 ft 6 in.
(762)
1 ft 10 3/8
in.
(568)
3 ft 1 5/8 in.
(956)
1 ft 10 3/8
in.
(568)
3 ft 1 5/8 in.
(956)
E,F 14 in.
(356)
10 in.
(254)
8 in.
(203)
1 ft 5 1/2
in.
(445)
2 ft 8 in.
(813)
1 ft 11 3/4
in.
(603)
3 ft 4 1/4 in.
(1,022)
1 ft 11 3/4
in.
(603)
3 ft 4 1/4 in.
(1,022)
49Model YK (Style G) Centrifugal Liquid Chiller
