SECTION 2 - INSTALLATION
FORM 160.75-N1
ISSUE DATE: 4/30/2014
2
TABLE 1 - ALLOWABLE COMPRESSOR / EVAPORATOR / CONDENSER / MOTOR COMBINATIONS
YK MOD G COMBINATIONS
COMPRESSOR
CODES
EVAPORATOR
CODES
CONDENSER
CODES
MOTOR CODES
60 HZ 50 HZ
Q3 AP to AS AP to AS
CF-CT
EF-ET
5CC-5CO
5EC-5EO
Q3, Q4
CP to CS CP to CS
DP to DS DP to DS
Q4 EP to ET EP to ET
Q5
CP to CS CP to CS
CH-CT
EH-ET
5CE-5CO
5EE-5EO
DP to DS DP to DS
Q5, Q6, Q7
EP to ET EP to ET
FQ to FT FQ to FT
P7
EP to ET EP to ET
CU-CY
EU-EV
5CP-5CU
FQ to FT FQ to FT
P8 GQ to GS EV to EX
CH-CZ
EH-EV
5CE-5CU
5EE-5EO
P8, P9
HQ to HS FV to FX
JP to JS JP to JS
LQ to LS LQ to LS
H9
KP to KS, K2 to K4 KP to KS, K2 to K4
CN-CA
EN-EV
5CK-5CW
5EK-5EO
MQ to MS, M2 to M4 MP to MS, M2 to M4
K1 KT to KX, K5 to K7 KP to KS, K2 to K4
CS-DC
ES-EV
5CN-5DC
5EN-5EO
K1, K2
MQ to MS, M2 to M4 MP to MS, M2 to M4
NQ to NS, N2 to N4 NP to NS, N2 to N4
PQ to PS, P2 to P4 PQ to PS, P2 to P4
QQ to QS, Q2 to Q4 QQ to QS, Q2 to Q4
K3
NQ to NS, N2 to N4 NP to NS, N2 to N4
DA-DJ 5DA-5DHQQ to QV, Q2 to Q4 QQ to QS, Q2 to Q4
RQ, RS, RV, R3, R5, R7 RQ to RS, R2 to R4
K4
RP, RR, RT, R2, R4, R6 RQ to RS, R2 to R4
DA-DJ 5DA-5DJ
SQ, SS, SV, S3, S5, S7
SQ to SS, S2 to S4
VP to VS, V2 to V5
XQ to XS, X2 to X4
TP to TS, T2 to T5
XQ to XS, X2 to X4
K7
WP-WT, W1, W2, W4, W6 WQ to WS, W1 to W4
DD-DL 5DD-5DL
ZQ to ZS, Z1 to Z4 ZQ to ZS, Z1 to Z4
YK MOD G HEAT RECOVERY COMBINATIONS
COMPRESSOR
CODES
EVAPORATOR
CODES
CONDENSER
CODES
MOTOR CODES
60 HZ 50 HZ
Q4 CP to CS BW, BX
CF-CT
EF-ET
5CC-5CO
5EC-5EO
Q7 EP to ET IW, IX
H9 KP to KS, K2 to K4 OW, OX, O8, O9
CN-CA
EN-EV
5CK-5CW
5EK-5EO
K2 MQ to MS, M2 to M4 UW, UX, U8, U9
CS-DC
ES-EV
5CN-5DC
5EN-5EO
K7 ZQ to ZS, Z1 to Z4 YW, YX, Y8, Y9 DD-DL 5DD-5DL
