SECTION 2 - INSTALLATION
YK MOD G HYBRID FALLING FILM COMBINATIONS
COMPRESSOR
CODES
HYBRID FALLING FILM
EVAPORATOR CODES
CONDENSER
CODES
MOTOR CODES
60 HZ 50 HZ
Q3
AC, AD, A3, A4 AP to AS
CF-CT
EF-ET
5CC-5CO
5EC-5EO
CC to CE, C3 to C5 CP to CS
Q4
CC to CE, C3 to C5 CP to CS
DC to DE, D3 to D5 DP to DS
Q5
CC to CE, C3 to C5 CP to CS
CH-CT
EH-ET
5CE-5CO
5EE-5EO
DC to DE, D3 to D5 DP to DS
Q5, Q6, Q7
EC to EE, E3 to E5 EP to ET
FC to FE, F3 to F5 FQ to FT
P7
EC to EE, E3 to E5 EP to ET
CU-CY
EU-EV
5CP-5CU
FC to FE, F3 to F5 FQ to FT
P8, P9
GC to GE, G3 to G5 EV to EX, E3 to E4
CH-CZ
EH-EV
5CE-5CU
5EE-5EO
HC to HE, H3 to H5 FV to FX, F3 to F4
H9
KC, KD, K8, K9, K0 KP, KQ, KR, KS, K2, K3, K4
CN-CA
EN-EV
5CK-5CW
5EK-5EO
IB, ID, IF, IH, I2, I4, I6, I8 KP, KQ, KR, KS, K2, K3, K4
MB, MD, MF, M5, M7, M8 MP, MQ, MR, MS, M2, M3, M4
K1 IB, ID, IF, IH, I2, I4, I6, I8 KP, KQ, KR, KS, K2, K3, K4
CS-DC
ES-EV
5CN-5DC
5EN-5EO
K1, K2
MB, MD, MF, M5, M7, M8, M9 MP, MQ, MR, MS, M2, M3, M4
NB, ND, NF, N5, N7, N8, N9 NP, NQ, NR, NS, N2, N3, N4
PB, PD, PF, P5, P7, P8 PQ, PR, PS, P2, P3, P4
QB, QD, QF, Q5, Q7, Q8 QQ, QR, QS, Q2, Q3, Q4
K3
NB, ND, NF, N5, N7, N8, N9 NP, NQ, NR, NS, N2, N3, N4
DA-DJ 5DA-5DH
QD, QF, QH, Q5, Q7, Q8, Q9 QQ, QR, QS, Q2, Q3, Q4
TABLE 1 - ALLOWABLE COMPRESSOR/EVAPORATOR/CONDENSER/MOTOR COMBINATIONS (CONT'D)
