JOHNSON CONTROLS
43
SECTION 2 - INSTALLATION
FORM 160.75-N1
ISSUE DATE: 4/30/2014
2
TABLE 3 - APPROXIMATE UNIT WEIGHT INCLUDING MOTOR FOR HYBRID FALLING FILM EVAPORATOR
UNITS - LBS (KGS)
SHELLS COMPRESSOR
SHIPPING WEIGHT
LBS. (KGS)
OPERATING WEIGHT
LBS. (KGS)
EST. REFRIGERANT
CHARGE LBS. (KGS)
A-A Q3 12,850 (5584) 14,419 (6266) 695 (302)
C-C Q3, Q4 14,570 (6331) 16,848 (7321) 875 (380)
C-C Q5 15,000 (6518) 17,278 (7508) 875 (380)
D-D Q4 17,000 (7387) 20,051 (8713) 1,180 (513)
D-D Q5 17,410 (7565) 20,461 (8891) 1,180 (513)
E-E Q5, Q6, Q7, P7 18,700 (8126) 21,700 (9429) 1,120 (487)
F-F Q5, Q6, Q7, P7 19,220 (8352) 23,142 (10056) 1,415 (615)
G-E P8, P9 20,640 (8969) 24,036 (10445) 1,320 (574)
H-F P8, P9 23,540 (10229) 28,083 (12203) 1,775 (771)
I-K H9 28,849 (12536) 34,078 (14808) 1,820 (791)
K-K H9 28,850 (12536) 34,079 (14809) 1,820 (791)
I-K K1 31,350 (13623) 35,145 (15272) 1,820 (791)
M-M K1, K2 34,520 (15000) 46,055 (20013) 2,300 (999)
N-N K1, K2 41,273 (17935) 49,605 (21555) 2,650 (1152)
N-N K3 48,380 (21023) 52,905 (22989) 2,650 (1152)
P-P K1, K2 41,950 (18229) 51,595 (22420) 3,100 (1347)
Q-Q K1, K2 45,800 (19902) 56,545 (24571) 3,500 (1521)
Q-Q K3 46,500 (20206) 59,945 (26048) 3,500 (1521)
NOTE: Refrigerant charge quantity and weights will vary based on tube count, conguration, and chiller performance. Use for reference only.
Refer to YORKworks Performance Page or chiller nameplate for actual charge requirement.
TABLE 4 - EVAPORATOR MARINE WATERBOX WEIGHTS - LBS (KGS)
(TO BE ADDED TO STANDARD UNIT WEIGHTS SHOWN IN TABLES 2 AND 3)
EVAPORATOR
CODE
SHIPPING WEIGHT OPERATING WEIGHT
INCREASE - LBS (KGS) INCREASE - LBS (KGS)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
A
924
(419)
744
(337)
978
(444)
1,468
(666)
1,288
(584)
1,522
(690)
C,D
1,352
(613)
1,114
(505)
1,480
(671)
2,224
(1,009)
1,986
(901)
2,352
(1,067)
E,F
1,878
(852)
1,260
(572)
2,080
(943)
3,378
(1,532)
2,760
(1,252)
3,580
(1,624)
G,H
1,213
550
1,296
(588)
1,293
(587)
2,655
(1,204)
2,738
(1,242)
2,735
(1,241)
I,J,K,L
1,751
(794)
1,843
(836)
1,856
(842)
3,864
(1,753)
3,956
(1,794)
3,969
(1,800)
M,N
4,290
(1,946)
2,036
(924)
4,140
(1,878)
7,535
(3,418)
3,264
(1,481)
6,300
(2,858)
P, Q
5,982
(2,713)
3,281
(1,488)
5,724
(2,596)
10,854
(4,923)
5,277
(2,394)
9,442
(4,283)
R,S,W
4,804
(2,179)
2,700
(1,225)
4,912
(2,228)
8,522
(3,866)
4,516
(2,048)
8,187
(3,714)
X,Z
7,088
(3,215)
3,660
(1,660)
7,244
(3,286)
11,552
(5,240)
5,507
(2,498)
11,243
(5,100)
