FORM 160.75-N1
ISSUE DATE: 4/30/2014
SECTION 2 - INSTALLATION
TABLE 5 - CONDENSER MARINE WATERBOX WEIGHTS - LBS (KGS)
(TO BE ADDED TO STANDARD UNIT WEIGHTS SHOWN IN TABLES 2 AND 3)
CONDENSER
CODE
SHIPPING WEIGHT OPERATING WEIGHT
INCREASE - LBS (KGS) INCREASE - LBS (KGS)
1-PASS 2-PASS 3-PASS 1-PASS 2-PASS 3-PASS
A
762
(346)
566
(257)
810
(367)
1,274
(578)
1,078
(489)
1,322
(600)
B
1,569
(712)
874
(396)
1,677
(761)
2,113
(958)
1,094
(496)
2,071
(939)
C,D
946
(429)
778
(353)
1,046
(474)
1,692
(767)
1,524
(691)
1,792
(813)
E,F
726
(329)
811
(368)
791
(359)
1,337
(606)
1,722
(781)
1,702
(772)
I
2,066
(937)
1,070
(485)
2,032
(922)
3,017
(1,396)
1,416
(642)
2,738
(1,242)
J,K,L
1,029
(467)
1,167
(529)
1,151
(522)
2,309
(1,047)
2,448
(1,110)
2,431
(1,103)
M,N
2,466
(1,119)
1,330
(603)
2,324
(1,054)
4,863
(2,206)
2,448
(1,110)
4,582
(2,078)
O
2,985
(1,354)
1,443
(655)
2,987
(1,355)
4,435
(2,012)
2,172
(985)
3,979
(1,805)
P, Q
3,700
(1,678)
1,858
(843)
3,752
(1,702)
6,561
(2,976)
3,132
(1,421)
5,991
(2,717)
R,S
3,806
(1,726)
1,946
(883)
3,960
(1,796)
6,657
(3,020)
3,195
(1,449)
6,352
(2,881)
V,T,W
5,196
(2,357)
2,565
(1,163)
5,204
(2,361)
9,161
(4,155)
4,012
(1,820)
8,219
(3,728)
U
3,641
(1,652)
1,893
(859)
3,609
(1,637)
5,350
(2,427)
2,556
(1,159)
4,770
(2,164)
X,Z
5,840
(2,649)
2,953
(1,339)
5,380
(2,440)
9,900
(4,491)
4,649
(2,109)
8,100
(3,674)
Y
9,094
(4,125)
4,762
(2,160)
9,058
(4,109)
13,326
(6,045)
6,524
(2,959)
12,409
(5,465)
