3-6
3-7
........... 2 pcs
2.6 x 12 mm Socket Head Bolt
............................. 2 pcs
2.6 mm Lock Nut
2.6 mm Lock Nut (2)
Tail Rotor Blade (2)
Tailblade Movement
2.6 x 12 mm Socket Head Bolt
................................ 2 pcs
2.6 x 12 mm Self Tapping Screw
.................................................. 2 pcs
2.6 mm Flat Washer
Vertical Fin
Horizontal Fin
2.6 x 12 mm Self Tapping Screw (2)
2.6 mm Flat Washer (2)
18
Tail Rotor Blade Installation
Vertical/Horizontal Fin Installation
Be careful not to over tighten
the 2.6 x 12 mm socket head
bolts when attaching the tail
rotor blades. The tailblades
should be able to move with
a slight amount of resistance
within the tail blade holders.
Although the angle of the horizontal fin is
adjustable, it is suggested that the horizontal fin
be installed horizontally (flat) in this step.
To Next Page
