REV.SW - SERVO REVERSING
Auto Dual Rate
H-15
Once all servos have been plugged into their proper
channels in the receiver, the first thing to check is the
direction of travel of each servo. Move all sticks and
switches/levers while observing each servo to determine
if the servos are moving in the correct directions. Make
note of those servos that are not traveling in the correct
direction and use the REV.SW function to reverse the
direction of travel for these servos.
1. Highlight and select REV.SW in the FUNC.LIST to
obtain the servo reversing display.
2. Use the Selector to highlight and select those
channels that need to be reversed. Pressing the
Selector toggles the channel between Normal
and Reverse.
Note: If any of the versions of CCPM have been
selected, the 3 CCPM channels will be re-named to
CH2, CH3, and CH6, etc. on the display.
The Automatic Dual Rate function allows you the
opportunity to change the dual rate and expo values of the
elevator, aileron, and rudder by changing the flight mode
or throttle hold switch positions.
This feature simplifies the operation of multiple switches
during flight.
To access the Auto D/R feature, simply roll the selector to
the right until the D/R Expo graph is replaced by the Auto
D/R Flight Mode list.
Highlight the Flight Mode to be set for Auto D/R, then
press the selector to pick the desired D/R setting to be
used for this flight mode. Repeat as necessary to assign
D/R positions for each flight mode.
[REV SW.]
THR AIL ELE RUD GER PIT AX2 AX3 AX4
REV.
NORM
[REV SW.]
THR CH2 CH3 RUD GER CH6 --- AX3 AX4
REV.
NORM
