JR X9303 User Manual

GYRO SENS/Gyro Gain Function
Accessing the Gyro Gain Function
H-28
The X9303 2.4 offers two different types of Gyro Gain
Sensitivity Adjustments: manual or automatic. This
feature gives the user the choice of selecting gyro
sensitivity through the rudder dual rate switch (AUX-2) or
automatically through the flight mode switch. The Gyro
Gain function allows you to have 2 different gyro gain
settings in Manual (RUDD D/R) mode, and 3 separate
gain settings in AUTO Mode.
If the manual (RUDD D/R) mode is selected, gain
changes are made manually by the pilot using the
Rudder D/R switch.
If Auto mode is selected, the Gyro gain is automatically
changed by linking directly to the Flight Mode switch.
If you do not intend to use this function, leave this
operation at the factory default position (OFF).
1. Place the transmitter switch in the ON position.
2. Press the LIST key to enter the Function mode.
3. Move the Rolling Selector and highlight the GYRO
SENS function. Press the Rolling Selector to access.
4. Highlight INH with the Rolling Selector, and then
press to open the options box. Highlight the desired
function type Manual (RUDD D/R) or AUTO, then
press the Rolling Selector to select.
5. Move the Rolling Selector to highlight the function
to be adjusted.
6. Press the Rolling Selector to select the gain position
to be adjusted, and then roll the Rolling Selector to
increase or decrease the gain values as needed.
7. If AUTO mode has been selected, once the gain values
for positions 0, 1, and 2 have been set, move the
Rolling Selector to highlight the mode positions
(NORM, ST-1, and ST-2), and select the gain
position (value) for each mode.
8. To exit the Gyro Gain function, move the Rolling
Selector to highlight LIST, and press.
[GYRO SENS]◊0
Pos.0 50%
Pos.1 50%
Pos.2 50%
NORM: Pos.0
ST-1: Pos.0
ST-2: Pos.0
AUTO
[GYRO SENS]◊0
Pos.0 50%
Pos.1 50%
RUDD D/R
