3 Operation
3.1 Adjusting Screens
3.1.1 Setting the Resolution
3.1.1.1 Display Resolution
For details on compatible resolutions, refer to “Compatible Resolutions” in the Setup Manual.
3.1.1.2 Setting Resolution
When the monitor is connected to the PC and the resolution is inferior, or when the resolution requires to be changed,
follow the procedure below:
Windows 10
1. Right-click the mouse anywhere on the desktop except foricons.
2. From the displayed menu, click “DisplaySettings”.
3. On the “Customize your display” dialog box, click “Advanced displaysettings”.
4. Select a monitor, then choose a resolution from the “Resolution” pull-downmenu.
5. Click the “Apply” button.
6. When a confirmation dialog box is displayed, click “Keepchanges”.
Windows8.1 / Windows 7
1. Click the “Desktop” tile on the Start Screen to display the desktop for Windows 8.1/ Windows 8, .
2. Right-click the mouse anywhere on the desktop except for icons.
3. Click SCREEN RESOLUTION on the displayed menu.
4. Select the monitor on the SCREEN RESOLUTION dialog box.
5. Click RESOLUTION to select the desired resolution.
6. Click the OK button.
7. Click KEEP CHANGES when a confirmation dialog box is displayed, .
Windows XP
1. Right-click the mouse anywhere on the desktop except for icons.
2. Click PROPERTIES on the displayed menu.
3. Click the “Settings” tab and select desired resolution for SCREEN RESOLUTION under “Display” on the “Display
Properties” dialog box displayed.
4. Click the OK button to close the dialog box.
Mac OS X
1. Select “System Preferences” from the Apple menu.
2. Click DISPLAYS for “Hardware” when the “System Preferences” dialog box is displayed.
3. Select the DISPLAY tab and select desired resolution in the RESOLUTIONS” field on the displayed dialog box. The
selection will be shown immediately.
4. Close the window, when the resolution is satisfactory.
12 | Operation
