1 Introduction
I Features
The AlphaScreen 19 and 26 have the following features
19.0″
LCD (FDS1904 / FDS1904T)
25.5″
LCD (FDU2603W / FDU2603WT)
Provides a display area (vertical: over 340 mm) required for radar on large ships.
Applicable to the resolution of 1280 × 1024. (FDS1904 / FDS1904T).
Applicable to the resolution of 1920 × 1200. (FDU2603W / FDU2603WT)
Panel with a wide field of view adopted.
• Horizontal : 178°, vertical : 178°(FDS1904 / FDS1904T).
• Horizontal : 176°, vertical : 176°(FDU2603W / FDU2603WT).
Dimming down to the low brightness.
Dimming down to the low brightness.
(You can set the brightness when “Brilliance” in the Adjustment menu is set to the lower limit value.) See Setting
Backlight Off Mode on page 22
The buttons on the front of the monitor light up.
The buttons on the front of the monitor (operation buttons) light up orange to enable the monitor to be operated in a
dark environment as well. Their brightness can also be adjusted. See Setting Brightness of Front Button on page 19
Cooling fan replacement is possible. See Replacing the Cooling Fan on page 31
Built-in warning buzzer.
Controlled on the system side.
Equipped with AC/DC power supplies.
Both AC power input and DC power input are provided to enable installation in various environments. In addition,
connecting both power inputs can provide a helpful backup if the AC power supply fails. (The AC power supply takes
priority during operation when both power inputs are connected.)
HDCP (High-bandwidth Digital Content Interface).
Type approval of ship classification.
This product has been approved for the following types of ship classifications:
• NK (Nippon Kaiji Kyokai)
• DNV GL (DNV GL AS)
• ABS (American Bureau of Shipping)
• LR (Lloyd’s Register of Shipping)
For the latest information on approvals for ship classifications, please refer to our website. http://www.eizoglobal.com
Testing Standards.
This product complies with the IEC60945 4
th
edition standard.
6 | Introduction
