3.5.3 Replacing the Cooling Fan
The cooling fan in this product can be replaced according to the following procedure.
Attention Be sure to follow the procedure when replacing the fan. Note that Alphatron Marine assumes no
responsibility for any damages caused due to improper handling of this product.
Note Contact Alphatron Marine for replacement parts.
Procedure
1. Remove the monitor from its enclosure.
1. Remove the screws that secure the monitor to the enclosure.
2. Lay the LCD monitor on a soft cloth spread over on a stable surface with the panel surface facing down.
2. Remove the fan cover.
Remove the four screws that secure the cover.
31 | Operation
