Communication Input Terminals
RS-232C: D-Sub 9-pin (female)
RS-232C: D-Sub 9-pin (male)
Port Upstream port × 1USB
Standard USB Specification Revision 2.0
AC Rating AC 100 - 240 V (Operating: AC 85 V - 264 V), 50/60 Hz, 0.65 A -
0.3 A
Input
DC Rating DC +24 V (Operating: +30% / -10%), 2.7 A (DC 24 V)
Maximum Power
Consumption
64 W or less
AC 9.0 W or lessPower Save
Mode
DC 6.0 W or less
(When there is DVI input, no USB device is connected,
and “Input Selection” is set to “Manual”, and when
DDC/CI is OFF)
AC 7.0 W or less
Power
Standby Mode
DC 5.0 W or less
(When there is DVI input, no USB device is connected,
and “Input Selection” is set to “Manual”, and when
DDC/CI is OFF)
Dimensions 429 mm × 406 mm × 74.5 mm (excluding the projection)Physical
Specifications
Net Weight FDS1904T: Approx. 6.4kg
FDS1904T-OP: Approx. 6.7kg
Temperature:
-15˚C
to
55˚C
Operating
Environmental
Requirements
Humidity 10% to 90% R.H. (no condensation)
Temperature:
-20˚C
to
60˚C
Transportation/
Storage
Environmental
Requirements
Humidity 10% to 92% R.H. (no condensation)
Viewing distance (Recommended) 1014 mm or more (*Based on IEC 62288)
Protection structure Front: IP65, Rear: IP22 (Landscape only)
39 | Specifications
