Communication Input Terminals
RS-232C: D-Sub 9-pin (female)
RS-232C: D-Sub 9-pin (male)
Port Upstream port × 1USB
Standard USB Specification Revision 2.0
AC Rating AC 100 - 240 V (Operating: AC 85 V - 264 V), 50/60 Hz, 1.2 A -
0.6 A
Input
DC Rating DC +24 V (Operating: +30%/-10%), 4.5 A (DC 24 V)
Maximum Power
Consumption
108 W or less
AC 10.0 W or lessPower Save
Mode
DC 7.0 W or less
AC 10.0 W or less
Power
Standby Mode
DC 7.0 W or less
Dimensions 624 mm × 456 mm × 86 mm (excluding the projection)Physical
Specifications
Net Weight FDU2603WT: Approx. 15.1 kg
FDU2603WT-OP: Approx. 15.9 kg
Temperature:
-15˚C
to
55˚C
Operating
Environmental
Requirements
Humidity 10% to 90% R.H. (no condensation)
Temperature:
-20˚C
to
60˚C
Transportation/
Storage
Environmental
Requirements
Humidity 10% to 90% R.H. (no condensation, wet bulb temperature
≤
39 °C)
Viewing distance (Recommended) 988 mm or more (*Based on IEC 62288)
Protection structure Front: IP65, Rear: IP22
