JRC JHS-183 - Voyage Data Settings; 5.3.1 Voyage Data Setting

5-16
5.3.1 Voyage data setting
Select 1. VOYAGE DATA in “5.3 MAIN MENU” screen, “VOYAGE DATA” menu screen for setting is
displayed.
Press ▲ key or ▼ key to select a desirable setting item and press ENT key, then selecting item and
inputting data are available.
To switch to “VOYAGE DATA” menu screen, press CLR key during selecting item or inputting data.
To switch to “MAIN MENU” screen, press CLR key at “VOYAGE DATA” menu screen.
When the SUB menu screen is displayed, press SUB or CLR key and switch to “VOYAGE DATA” menu
screen.
Select [SET] at the sub menu screen, the setting is saved. If [EXIT] is selected at the sub menu screen,
the screen is returned to “MAIN MENU”.
In order to select a destination from past inputted destinations, Select [DEST LOAD] at the sub menu.
(Refer to “5.3.1.7 Re-load destination”.)
The outline of the each menu is as follows:
1. NAV. STATUS･･･select navigational status. (Refer to 5.3.1.1)
2. DESTINATION･･･input the destination. (Refer to 5.3.1.2)
3. ETA･･･input ETA(expected time for arrival). (Refer to 5.3.1.3)
4. DRAUGHT･･･input draught value.( Refer to 5.3.1.4)
5. PERSONS ON-BOARD･･･input the number of persons on-board.( Refer to 5.3.1.5)
6. SHIP TYPE U.S･･･select type ship.( Refer to 5.3.1.6)
7. TYPE OF SHIP/CARGO･･･select ship/cargo/status.( Refer to 5.3.1.7)
Caution: In order to save the setting, select [SET] at the SUB menu.
If you switch to any other screen without selecting [SET], the setting is not saved.
▲
or
▼
SUB
or
CLR
VOYAGE DATA
*SUB MENU*
[
SET
]
[
DEST LOAD
]
[
EXIT
]
V O YAGE DATA
1 .NAV.STATUS:
ENGAGED IN F ISHING
2 .DESTINATION :
J APAN
3 .ETA:
▼
12/30 12:23
1/3
V O YAGE DATA
▲
4 .DRAUGHT:
12.5M
5 .PERSONS ON B OARD:
0191
6 .SHIP TYPE U . S:OFF
▼
2/3
V O YAGE DATA
▲
7 .TYPE OF SHI P /CARGO
T YPE OF SHIP: 2 0
WIG
C ARGO TYPE
ALL SHIPS OF THIS>
3/3
