5-37
5.3.3 Maintenance
Select 3.MAINTENANCE in “MAIN MENU” screen, “MAINTENANCE” menu screen is displayed.
It is possible to check the current status with “Maintenance” menu screen.
In order to return to MAIN MENU screen, press CLR key.
The outline of the each menu item is as follows:
1. SELF DIAGNOSIS ･･･Execute the self diagnosis test. (Refer to 5.3.3.1)
2. COMMUNICATION TEST ･･･Transmits an interrogation message and then confirms the result for
communication check.(Refer to 5.3.3.2)
3. AIS ALARM ･･･Displays malfunction alarms. (Refer to 5.3.3.3)
4. SENSOR STATUS ･･･Displays current status of sensors. (Refer to 5.3.3.4)
5. EVENT LOG ･･･Displays the history of power ON/OFF and so on. (Refer to 5.3.3.5)
6. SOFTWARE VERSION ･･･ Displays software versions installed. (Refer to 5.3.3.6)
MAINTENANCE
1.SELF DIGNOSIS
2.COMMUNICATION TEST
3.AIS ALARM
4.SENSER STATUS
5.EVENT LOG
6.SOFTWARE VERSION
To Next Page
