5-28
d) Transmitting and Saving
If “FUNCTION” in Message Type (refer to “a) MESSAGE”, and “b) MESSAGE TYPE SETTING”) is
“TEXT”, operate transmitting or saving a message according to the following procedure:
- After editing, select “SAVE” in SUB menu. Then the message is saved in TX TRAY.
- If [EXIT] is selected, return to “EDIT AND TX” screen for message type setting.
Select [TX] in “EDIT AND TX” sub screen and press ENT key. A confirmation message is appeared.
If select [OK], the message is transmitted. After its acknowledgement is received, “RESULT: ACK OK” is
displayed. Press [OK] and then return to “EDIT AND TX” screen.
In case of ADDRESSED In case of BROADCAST
e) SETTING TIMES OF RETRY
When AIS transmits the individual message (FORMAT: ADDRESSED), the acknowledgement of
receiving the message is replied from the destination. If the acknowledgement could not be received
after transmitting, the transmission is retried.
The Numbers of retry can be set between 0 and 3 times. However, when the numbers of retry is set to
0~2 times (except 3 times), its numbers is changed to 3 times as the default after 8 minutes.
6. NUMBER OF RETRY: 3
6. NUMBER OF RETRY: 3 6. NUMBER OF RETRY: 1
Set to 0~2 with ▲ key or ▼ key Change to “3” after 8 minutes
EDIT AND TX
*SUB MENU*
