MENU SETTING
DISPLAY CONTRAST 1 2 3 4 5 6 7 8 9 10 11 12 13
DIMMER MAXIMUM 1 2 3 4 5 6 7 8 9 10
TYPICAL 1 2 3 4 5 6 7 8 9 10
MINIMUM 1 2 3 4 5 6 7 8 9 10
CLICK SOUND ON OFF
REVERSING MODE NORMAL REVERSE1 REVERSE2
START SCREEN COMP-A -B -C -D -E -F HDG SOG COG
NAVI-
A
-B ROT-
A
-B SPEED GRAPH CALC
DECIMAL FONT SIZE L
A
RGE SMALL
COMP-C/D POSN DIGIT 3 4
CURRENT LAYERS
(1～999) ALL
HEADING RESTORATION AUTO MANUAL
BACKUP 1 2 3 4 5
INTERRUPT NMEA NULL LAST STOP
HEADING OFFSET
(-10～+10)
OUTPUT RESOLUTION 0.1 0.01
GPS MODE
A
UTO 2D 3D
HDOP 4 10 20
SMOOTHING POSITION
(0～99)
SPEED
(0～99)
COURSE
(0～99)
RAIIM ACCURACY LEVEL
OFF 10 30 50 100
INITIALIZATION LATITUDE
LONGITUDE
ANT HEIGHT
SBAS MODE
A
UTO GPS
A
LONE SBAS BEACON
SBAS SEARCH
A
UTO MANUAL
TYPE 0 INFORMATION ON OFF
RANGING ON OFF
BEACON STATION SELECT MANUAL AUTO
BIT RATE 50 100 200
FREQUENCY
(275.0～325.0)
BEACON INFORMATION ON OFF
SYSTEM TIME DIFF
(-13:00～+13:00)
DATE DISP DD-MM’YY ‘YY-MM-DD MM-DD’YY
DD MMM,’YY MMM DD,’YY
TIME DISP 12 24
DATUM
SPEED UNIT kn km/h mi/h
ROT RANGE 30 60 90 120 150 180 210
240 270 300 600 900 1200 1500
1800 2100 2400 2700
ROT SMOOTHING
(0～99)
ROLL/PITCH RANGE 5 10 15 20 25 30
ROLL OFFSET
(-30～+30)
PITCH OFFSET
(-30～+30)
SYSTEM2 HEAVING BAR RANGE 1 2 3 4 5 10 20 30 40 50 100
HEAVING BAR DISP OFF DISP1 DISP2 DISP3 DISP4
TREND GRAPH
A
VERAGE MAXIMUM
HVE POINT OFFSET X
HVE POINT OFFSET Y
HVE POINT OFFSET Z
RMC MAG CORR
A
UTO MANUAL
GPS 5Hz DRAW ON OFF
SOG BAR R
A
NGE 5 10 15 20 25 30 50 100
