Section 5 Operation
5.1 Menu List
5.1.1 Menu List
MAIN MENU
├
DISPLAY ┬ CONTRAST 1～7～13
│ ├
DIMMER
┬
MAXIMUM
1～9～10
│ │ ├ TYPICAL 1～6～10
│ │ └
MINIMUM
1～4～10
│ ├ CLICK SOUND ON/OFF
│ ├ REVERSING MODE NORMAL,REVERSE1,REVERES2
│ ├ START SCREEN
COMP-A,-B,-C,-D,-E,-F,HDG,SOG,COG,NAVI-A,-B,ROT-A,-B,
SPEED, GRAPH, CALC
│ ├ DECIMAL FONT SIZE LARGE, SMALL
│ ├ COMP-C/D POSN DIGIIT 3,4
│ └ CURRENT LAYERS ALL 1～3～999
│
├ HEADING ┬ RESTORATION AUTO,MANUAL
│ ├ BACKUP 1,2,3
│ ├ INTERRUPT NMEA NULL,STOP
│ ├ HEADING OFFSET `-10.0°～0.0°～+10.0°
│ └
OUTPUT
RESOLUTION
0.1,0.01°
│
├ GPS ┬ MODE AUTO,2D,3D
│ ├ HDOP 4,10,20
│ ├ SMOOTHING ┬ POSITION 0～10～99s
│ │ ├ SPEED(SOG) 0～4～99s
│ │ └ COURSE(COG) 0～4～99s
│ ├ RAIM ACCURACY LEVEL OFF,10,30,50,100m
│ └ INITIALIZATION ┬ LATITUDE
│ ├ LONGITUDE
│ ├ ANT HEIGHT
│ ├ DATE DD-MM’YY
│ └ UTC HH:MM:SS
│
├ SBAS ┬ MODE AUTO,GPS ALONE,SBAS,BEACON
│ ├ SBAS SEARCH AUTO,MANUAL
│ ├
TYPE 0
INFORMATION
ON,OFF
│ └ RANGING ON,OFF
│
├ BEACON ┬ STATION SELECT MANUAL,AUTO
│ ├ BIT RATE 50,100,200bps
│ ├ FREQUENCY 283.5～325.0kHz
│ └ BEACON INFORMATION ON,OFF
│
├ SYSTEM ┬ TIME DIFF `-13:00～00:00～+13:00
│ ├ DATE DISP
DD-MM’YY,’YY-MM-DD,MM-DD’YY
DD MMM,’YY MMM DD,’YY
│ ├
TIME DISP 12,24
│ ├
DATUM WGS84,WGS72,JAPAN,………SPK
│ ├
SPEED UNIT kn,km/h,mi/h
│ ├ ROT RANGE ┌ ±30,60,90,120,150,180,
│ │ │ 210,240,270,300,600,900,
│ │ └ 1200,1500,1800,2100,2400,2700°/min
│ ├ ROT SMOOTHING 0～10～99s
│ ├ ROLL/PITCH RANGE ±5,10,15,20,25,30°
│ ├ ROLL OFFSET `-30～0～+30°
│ └ PITCH OFFSET `-30～0～+30°
│ NEXT PAGE
