3-3
3.2 NNN-21/31 Sensor Unit
● Unit
The diagram shows the NNN-21, but applies to the NNN-31 as well.
NNN-21
BOW
GPS3
(Antenna)
Processor
GPS2
(Antenna)
GPS1
(Antenna)
Data Cable
