4-4
SOG Screen
COG Screen
4.1.3 Navigation Screen
The latitude and longitude of the ship's position are displayed.
Latitude and longitude displays (3 decimals or 4 decimals display)
can be cycled between using the and keys.
SOG: Speed over
ground
Bow heading (HDG)
COG: Course over
ground
RAIM information:
The following information is displayed in the
configured accuracy level. (Refer to 5.3.3. GPS
Configuration (GPS).)
RAIM ON: Displays the configured accuracy
level (10m 30m 50m 100m)
RAIM OFF: RAIM OFF
No failed satellite: SAFE
Unable to RAIM: CAUTION
Occurrence of a failed satellite: UNSAFE SATID XX
(XX is satellite No.)
"-": Less than 1 knot.
COG "-": Less than 1 knot.
