JRC JLR-21 - Decimal Display Size Setting (DECIMAL DISP SIZE); Current Position Display Digit Setting on Compass Screens C;D (COMP-C;D POSITION DIGIT)

5-17
5.3.1.6 Decimal Display Size Setting (DECIMAL DISP SIZE)
The display size of decimals on the screen assigned to the DISP key (refer to 4.1 Display Screen) can
be selected.
LARGE: The display size of decimal numbers is large. Ex.
SMALL: The display size of decimal numbers is small. Ex.
Applicable screens are Compass Screens A to F, Bow Heading Screen, Navigation Screen, Turn Rate
Screen, and Water Speed/Ground Speed Screen.
5.3.1.7 Current Position Display Digit Setting on Compass Screens C/D (COMP-C/D POSITION
DIGIT)
The number of digits for displaying the current position on the Compass screens C/D can be selected.
3: The current position is displayed with 3 decimals. Ex.
4: The current position is displayed with 4 decimals. Ex.
