5-2
├ SYSTEM 2 ┬ PREVIOUS PAGE
│
├ HEAVING BAR RANGE 1,2,3,4,5,10,20,30,40,50,100
│
├ HEAVING BAR DISP OFF,DISP1,DISP2,DISP3,DISP4
│
├ TREND GRAPH AVERAGE,MAXIMUM
│
├ HVE POS OFFSET ┬ X -999.9～+0.0～+999.9m
│
├ ├ Y -999.9～+0.0～+999.9m
│
├
└ Z -999.9～+0.0～+999.9m
│
├
RMC MAG CORR AUTO,MANUAL
│
├
GPS 5Hz DRAW ON,OFF
│
└ SOG BAR RANGE 5,10,15,20,25,30,50,100
│
├ DATA I/O ┬ SENSOR THROUGH NMEA,NSK,AD-10,IEC
│ ├ DATA OUT1 NMEA,NSK,AD-10,IEC
│ ├ DATA OUT3 NMEA,NSK,IEC
│ ├ DATA OUT4/IN4
NMEA/OFF,NSK/OFF,BEACON/OFF,IEC/OFF,4341/OFF,
NMEA/CURRENT,BEACON/CURRENT,IEC/CURRENT,
4341/CURRENT,NMEA/CCRP,BEACON/CCRP,IEC/CCRP,4341/CCRP
│ │ BEACON/CURRENT
│ ├ DATA OUT5 NMEA,NSK,IEC
│ └ LOG PULSE OFF,200p/nm,400p/nm
│
├ VERSION INFO DISPLAY,SENSOR,GPS1,GPS2,GPS3
│
├ ALERT － ALERM ESCALATION ┬ POSITION OFF,ON
│ │ ├ HEADING. OFF,ON
│ │ └ TIME 30,60,120,180,240,300
│ ├ HEADER ALERT DISP OFF,ON
│ ├ DGPS ALERT OFF,ON
│ └ TEST MODE OFF,ON
│
└ LANGUAGE ENGLISH,JAPANESE
MAIN MENU(M)
├
ANT CHECK
│
├ INPUT CHECK ─ PORT SELECTION START,STOP OFF,INPUT0,INPUT4
│
├ DIAGNOSIS ┬ DISPLAY OFF,START
│ ├ SENSOR OFF,START
│ └ LCD OFF,START
│
├ DEMO ─ DEMO TYPE OFF,01～99
│
├ PRODUCT TYPE ┬ DISPLAY ┬ TYPE MAIN,SUB
│ │ ├ SERIAL
│ │ └ SFI
│ └ SENSOR ┬ SERIAL
│ ├ BARCODE
│ └ DEFAULT No. 0
│
├ RESET ┬ DISPLAY NO,YES
│ ├ SENSOR NO,YES
│ └ ALL NO,YES
│
├ SOFT UPDATE ┬ UPDATE AREA SENSOR,DISPLAY
│ └ BIT RATE FROM PC ┬ SENSOR AUTO
│ └ DISPLAY 38400,57600,115200bps
│
└ CCRP ┬ SHIP DISABLE,ENABLE
├
BEAM 1.0～70.0
├ LENGTH 1.0～700.0
├
SENSOR DISABLE,ENABLE
├ SENSOR No.1～No.9
├ X -35,0～0.0～35.0
├ Y 0.0～700.0
├ CCRP DISABLE,ENABLE
├ X -35,0～0.0～35.0
└ Y 0.0～700.0
To Next Page
