5-3
* The underlined settings are factory defaults. If the equipment is master-reset, all the parameters are
configured to defaults.
* CCRP settings will not be initialized by master reset.
●Default of DATA I/O
Name on Display Set item Default
SENSOR THROUGH NMEA VER NMEA Ver2.1
BIT RATE 38400bps
INTERVAL(HDT,THS,ROT) 25msec
SENTENCE HDT ROT
DATA OUT1 NMEA VER NMEA Ver2.1
BIT RATE 4800bps
SENTENCE
―（None）
DATA OUT2 NOT USED
DATA OUT3 NMEA VER NMEA Ver2.1
BIT RATE 4800bps
SENTENCE GGA VTG RMC GLL (Interval is 1 sec.)
DATA OUT4 NMEA VER NMEA Ver2.1
BIT RATE 4800bps
SENTENCE
―（None）
DATA OUT5 NMEA VER NMEA Ver2.1
BIT RATE 4800bps
SENTENCE
―（None）
