5-20
• HEADING OFFSET: The heading can be offset from -10.0º to +10.0º.
The output heading to external devices is also offset.
If an offset value is entered (any value other than 0), "H" will appear in
the status bar at the bottom of the screen.
The sensor shall always be installed parallel to the keel, but in the
event that this is impossible, the error can be aligned here.
• OUTPUT RESOLUTION: Sets the resolution of the HDT (THS) sentence output.
0.1 or 0.01 can be selected.
(Normally, select the default value of 0.1)
• Press to return to the Main Menu.
• In Maintenance Mode settings can be changed press and hold both and for 3
seconds or more to go to the mode.
Memo
