APPENDIX
A-1
8
Item Setting Contents
3. TTD Off / GPS / NMEA1 / NMEA2 / NMEA3
4. TLB Off / GPS / NMEA1 / NMEA2 / NMEA3
5. GGA Off / GPS / NMEA1 / NMEA2 / NMEA3
6. GLL Off / GPS / NMEA1 / NMEA2 / NMEA3
7. RMC Off / GPS / NMEA1 / NMEA2 / NMEA3
8. VTG Off / GPS / NMEA1 / NMEA2 / NMEA3
9. OSD Off / GPS / NMEA1 / NMEA2 / NMEA3
10. RSD Off / GPS / NMEA1 / NMEA2 / NMEA3
11. THS Off / GPS / NMEA1 / NMEA2 / NMEA3
12. HDT Off / GPS / NMEA1 / NMEA2 / NMEA3
5. TX Data Format
1. TX Interval 1 䇵 9 second
2. NMEA Version V2.3 / V2.0 / V1.5
3. NMEA Talker Normal / GP
6. Target Information TX
1. TX Target TT / AIS / TT/AIS
2. TTM Distance Accuracy 1 / 2 / 3
3. TTM Average Mode Off / On
4. TTM Average Scan 2 - 10
8. Buzzer
1. Key ACK 0 - 255
2. Operation㻌 Error 0 - 255
3. CPA/TCPA 0 - 255
4. AZ/Alarm Zone 0 - 255
5. Target Lost 0 - 255
6. System Alarm 0 - 255
7. External
1. CPA/TCPA Off / On
2. AZ/Alarm Zone Off / On
3. Target Lost Off / On
4. System Alarm Off / On
5. Out of Range Off / On
9. GPS
1. NMEA Version Auto / V1.5 / V2.1 / V2.3
2. GPS Setting
1. Correction Method GPS Single / SBAS / Beacon / AUTO
2. Fix Mode 2D / 3D / AUTO
3. Elevate Mask 5 - 89㼻
4. HDOP 4 / 10 / 20
5. Smooth Lat/Lon 0 䇵 99 sec(R34.00 - )
6. Smooth SOG 0 䇵 99 sec(R34.00 - )
7. Smooth COG 0 䇵 99 sec(R34.00 - )
8. Smoothing1
0 䇵 99 sec(R29.04 - R33.99)
1 䇵 99 sec(R26.01 - R29.03)
9. Smoothing2 0 sec / 10 sec / 40 sec( - R26.00)
10. RAIM Accuracy Level Off / 10m / 30m / 50m / 100m
11. Exclusion Satellite
1. Exclusion Satellite 1 0 䇵 32
2. Exclusion Satellite 2 0 䇵 32
3. Exclusion Satellite 3 0 䇵 32
4. Exclusion Satellite 4 0 䇵 32
5. Exclusion Satellite 5 0 䇵 32
6. Exclusion Satellite 6 0 䇵 32
12. Send Data
13. GPS Adjust
1. Position
