JRC JMA-3404 User Manual

A-19
APPENDIX
Item Setting Contents
1. Latitude S/N 0㼻00.0000䇻 䇵 90㼻00.0000䇻
2. Longitude E/W 0㼻00.0000䇻 䇵 180㼻00.0000䇻
2. Antenna Height 0 䇵 8191
3. Time 00:00:00 䇵 23:59:59
4. Date 2010/01/01 䇵 2099/12/31
5. Master Reset
6. Send Data
3. Beacon Setting
1. Select AUTO / Manual
2. Frequency 283.5 䇵 325.0
3. Baud Rate 50bps / 100bps / 200bps
4. Send Data
4.SBAS Setting
1. Satellite Search AUTO / Manual
2. Ranging Off / On
3. SBAS Satellite Number 120 䇵 138
4. Send Data
5. Display GPS Receive Status
6. LORAN Setting
1. Display Time Zone Off / LORAN A / LORAN C
2. LORAN A
1. Select 1
1S1 / 1S2 / 1S3 / 1S4 / 1S6 / 1L0 / 1L1 / 1L4 / 1L5 / 2S0 / 2S1 / 2S2 / 2S3
/ 2S4 / 2S5 / 2S6 / 2S7 / 2H4 / 2H5 / 2H6
2. Select 2
1S1 / 1S2 / 1S3 / 1S4 / 1S6 / 1L0 / 1L1 / 1L4 / 1L5 / 2S0 / 2S1 / 2S2 / 2S3
/ 2S4 / 2S5 / 2S6 / 2S7 / 2H4 / 2H5 / 2H6
3. TD1 Correction 0.0 - 9.9
4. TD2 Correction 0.0 - 9.9
3. LORAN C
1. Chain
4990 / 5930 / 5970 / 5980 / 5990 / 6730 / 6731 / 6780 / 7001 / 7030 / 7170
/ 7270 / 7430 / 7499 / 7930 / 7950 / 7960 / 7970 / 7980 / 7990 / 8000 /
8290 / 8390 / 8830 / 8930 / 8970 / 8990 / 9007 / 9610 / 9930 / 9940 / 9960
/ 9970 / 9980 / 9990
2. TD1 0 䇵 99
3. TD2 0 䇵 99
4. TD1 Correction 0.0 䇵 9.9
5. TD2 Correction 0.0 䇵 9.9
10. Control
1. Multi Control Menu Time Out 0 䇵 255
2. Cross Key Gain 1 – 5
3. Trackball Control 1 – 5
4. Multi Control
1. EBL 1 – 5
2. VRM 1 – 5
3. Common 1 – 5
5. Gain Control
1.㻌 Response Level 1 – 5
2. Gain Min Preset 0 – 127
3. Gain Max Preset 128 – 255
6. Sea Control
1. Response Level 1 – 5
2. Sea Min Preset 0 – 127
3. Sea Max Preset 128 – 255
7. Rain Control
1. Response Level 1 – 5
2. Rain Min Preset 0 – 127
3. Rain Max Preset 128 – 255
11. Maintenance
1. Reset Partial
